The C-SBU series motor bracket unit from SUNG-IL MACHINERY is a high-precision assembly solution designed to simplify machine design, improve assembly accuracy, and enhance overall system performance. By integrating the motor mounting system with the ball screw support unit, the C-SBU Series minimizes installation errors, reduces vibration, and increases productivity across various industrial automation applications.
Whether used in CNC machinery, semiconductor equipment, automation systems, or precision motion control applications, the C-SBU Series delivers superior reliability, rigidity, and operational efficiency.
Key Features and Benefits
Technical Precision
The C-SBU Series is engineered to eliminate cumulative assembly errors commonly found in conventional motor and support unit installations. The integrated design ensures:
- Improved alignment accuracy
- Reduced shaft runout
- Lower vibration levels
- Enhanced motion stability
- Increased machine precision
Process Efficiency
By combining critical mounting components into a single assembly, the C-SBU Series helps manufacturers streamline engineering and production processes.
Benefits include:
- Simplified machine design
- Reduced assembly time
- Easier component management
- Faster project lead times
- Improved production workflow
Cost-Effective Performance
The optimized structure contributes to lower manufacturing costs and improved productivity.
Advantages include:
- Reduced installation errors
- Lower maintenance requirements
- Increased equipment uptime
- Improved manufacturing competitiveness
- Enhanced long-term operational value
Fixed Side Support Unit
The fixed side support unit is manufactured with high accuracy and preloaded bearings to ensure smooth operation without runout.
Available Configurations
- Support Unit Mounted Type
- Bearing Mounted Type
- Clean (Closed) Type
- Open Type
Each unit is supplied with:
- High-precision lock nut
- Precision collar (spacer)
- Factory-applied preload for optimal performance
This design provides superior rigidity, positioning accuracy, and long service life.
Supported Side Unit
The supported side unit is equipped with:
- Deep-groove ball bearing
- Snap-ring assembly
An optional damper-attached version is also available to further reduce vibration and improve operational stability in demanding applications.
